Insultation Tape

  • Insultation Tape

Insultation Tape

  • To use

    • Mainly used for various transformer insulation, motor insulation, and DY fixing.

  • Advantage

    • Excellent adhesion, heat resistance, insulation properties, and flexibility.

Product Structure

표를 밀어서 확인해보세요.

Contents Grade  Base Meaterial  Total
   Thickness   		 Adhesive force
(180℃ peel * gf/25mm)		 Heat
Resistance(℃)		 Remark
Acrylic Tape MP-200P   Polyester 25 ㎛ Min. 600 130 UL FILE NO.E208997
MP-200P Polyester 50 ㎛ Min. 700 130 UL FILE NO.E208997
  DPA-820 Non-woven+PET 120 ㎛  Min. 400 130 UL FILE NO.E208997
DPA-230B  Glass Cloth 215 ㎛ Min. 750 130 UL FILE NO.E208997
DPA-280 Non-woven+PET 220 ㎛ Min. 500 130
MP-300SG Glass Cloth 220 ㎛ Min. 600 180 UL FILE NO.E208997
DPA-232F Glass Cloth 230 ㎛ Min. 620 155 UL FILE NO.E208997
M-100A Acetate Cloth 250 ㎛ Min. 700 105 UL FILE NO.E208997
